The Machinable Pitbull Clamp is made of tool steel and heat treated to about 43RC for long life, yet still machinable. There is additional material on the clamping face to allow for machining a radius.
| Clamp Width | 1.00 in |
|---|---|
| Dimension C | 1.00 in |
| Holding Force | 6000 LBS |
| Max Torque | 30 FT/LBS lb-in |
| Dimension A | .400 in |
| Dimension B | .450 in |
| Screw Size | 3/8-16 |
| Dimension D | .250 in |
| Dimension E | .710 in |
| Type | Tool Steel |
| Color Family | Black |
| Country of Origin | Made in USA |
| Description | Machinable Pitbull® Clamp |
| Package Quantity | 4 |
| Manufacturers Part Number | 26077 |
| Brand | Mitee-Bite |
