Name: Mitee-Bite 23140 - Multi-Fixture Clamps And Stops - Clamp W/ Step 2.50&quot; - Min Qty 2 - Made In USA
SKU: Mitee-Bite WBB736395
Availability: InStock

New

Mitee-Bite 23140 - Multi-Fixture Clamps And Stops - Clamp W/ Step 2.50" - Min Qty 2 - Made In USA

Original price was: $81.95.Current price is: $57.37.

SKU: Mitee-Bite WBB736395 Categories: Clamping & Positioning, Clamps & Components, Fixturing Clamps Tags: 1, 23140, Black, Machining, Made in USA, Mitee-Bite, Multi-Fixture Clamp, With Step

Quality and Affordability Combined
Experience the difference quality makes.
Buy Quality, Live Better
Have the best deals

Multi-Fixture Clamps and Stops – Clamp w/ Step 2.50″

Tapered mounted slot prvevents movement when clamping pressure is applied. Provides flexible set ups for hard to hold parts. Can be mounted vertically or horizontally. Stops locate workpiece for repeat positioning. Larger sizes are ideal for mold shop applications. All clamps available in metric sizes.

Dimension F	.83 in
Dimension C	.62 in
Holding Force	2000 LBS
Max Torque	8.3 FT/LBS lb-in
Dimension A	2.50 in
Dimension B	.75 in
Screw Size	3/8-16
Dimension D	.4600 in
Dimension E	.31 in
Type	With Step
Color Family	Black
Country of Origin	Made in USA
Package Quantity	1
Description	Multi-Fixture Clamp
Manufacturers Part Number	23140
Brand	Mitee-Bite
